Analysis with SolidWorks SEngineering imulation 2011 byPaul M. Kurowski, Ph.D., P.Eng.
Topics covered:
Using the SolidWorks Simulation interface
Linear static analysis with solid elements
Controlling discretization error with the convergence process
Finding reaction forces
Presenting FEA results in a desired format
Project description:
A steel plate is supported and loaded, as shown in Figure 2-1. We assume that
the support is rigid (this is also called built-in support, fixed support or fixed
restraint) and that a 100000N tensile load is uniformly distributed along the
end face, opposite to the supported face. We will perform a displacement and stress analysis using meshes with different element sizes. Note that repetitive analysis with different meshes does not represent standard practice in FEA. The process does however produce results which are useful in gaining more insight into how FEA works.
